CEQU PSKD Fixed Firefighting Monitor is a firefighting product with world-class technology. It is an ideal firefighting device for extinguishing solid material fires. The monitor features a large flow rate, long range, and supports both wired and wireless control. The motor and junction box are waterproof. The electrical control cabinet can be placed in the control room for remote operation and positioning, helping ensure the safe evacuation of firefighters from the fire scene and guaranteeing safe and effective fire suppression.
|
Specification |
|||||||
|
Model |
PSKD20 |
PSKD30 |
PSKD40 |
PSKD50 |
PSKD60 |
PSKD80 |
PSKD100 |
|
Flow Rate (L/S) |
20 |
30 |
40 |
50 |
60 |
80 |
100 |
|
Rated Working Pressure (Mpa) |
0.8 |
1.0 |
1.2 |
||||
|
Max Working Pressure |
1.6 Mpa |
||||||
|
Water Throw (m) |
≥50 |
≥60 |
≥65 |
≥70 |
≥75 |
≥85 |
≥90 |
|
Max Spray Angle |
≥90 ° |
||||||
|
Horizontal Rotation Angle |
360 ° |
||||||
|
Min Depression Angle |
≤-60 ° |
||||||
|
Max Elevation Angle |
≥+60° |
||||||
Remote Control Operation:
The PSKD Remote Control Monitor allows operators to control the monitor's movement, water flow, and spray pattern from a distance, providing enhanced safety and convenience during fire operations.
High Efficiency and Reach:
Capable of projecting water at high pressures and long distances, ensuring rapid fire suppression even in hard-to-reach areas. It can handle a wide range of fire sizes, from small fires to large-scale industrial blazes.
Adjustable Nozzle & Spray Patterns:
Equipped with an adjustable nozzle, the monitor offers multiple spray patterns, including fog, straight stream, and wide spray. This flexibility allows it to adapt to different firefighting needs.
Durable Construction:
Built with corrosion-resistant materials and designed to withstand extreme environmental conditions, including high temperatures and corrosive chemicals, making it ideal for industrial and outdoor applications.
Easy to Transport and Install:
The PSKD monitor is lightweight and can be mounted on various platforms, including vehicles, fixed stations, or mobile units. Its user-friendly design makes installation and transportation simple and efficient.
Advanced Control System:
The remote control system features intuitive controls for easy operation, even in high-stress situations. Operators can adjust the monitor's position, spray angle, and water flow quickly to respond to changing conditions.
Typical Sites: Chemical plants, power stations, factories
- Ideal for fighting fires in hazardous and difficult-to-reach areas, such as high shelves or confined spaces.
- Remote operation keeps operators at a safe distance from potential chemical spills or explosions.
Typical Sites: High-rise buildings, residential complexes, commercial centers
- Provides high reach to extinguish fires on upper floors of tall buildings.
- Flexible spray patterns allow quick adaptation to different fire situations in urban environments.
Typical Sites: Oil refineries, pipelines, storage tanks
- High-pressure water or foam output for flammable liquid fires.
- Remote control ensures safe operation when dealing with hazardous materials.
Typical Sites: Forests, grasslands, national parks
- Long-range water stream helps to suppress fires over vast areas.
- Portable and easy to set up on mobile units for quick deployment in emergency situations.
Typical Sites: Underground tunnels, metro stations
- Remote operation allows firefighting personnel to stay out of the hazardous smoke and heat zones.
- Effective in suppressing fires in confined spaces with limited access.
Typical Sites: Firefighting training centers, industrial emergency drills
- Simulates real firefighting conditions in training exercises.
- Provides a safe, controlled environment for training operators in high-pressure scenarios.
Packaging & Shipping
Wooden Crate Packaging:
For added protection during transport, our products are packaged in high-quality wooden crates. This packaging ensures that the items are secure and safeguarded against potential damage during shipping. Wooden crates are particularly suitable for fragile or oversized equipment, providing an extra layer of protection against external impacts.
