Large Flow | Long Range | Flexible Operation
CEQU PS Fixed Fire Monitor Brass Nozzle is portable monitors are devices used to deliver large water flows for fire fighting purposes in high risk or hazardous industries. Industrial portable monitors are used by private industrial fire professionals to protect high risk environments.
|
Type |
PS Fixed PS Fixed Fire Monitor Brass Nozzle |
|
Model |
PS20W,PS30W,PS40W,PS50W |
|
Flow Rate |
20~50L/S |
|
Working Pressure |
6~16Bar |
| Flow Range | 20~60M |
|
Angle of Horizontal Rotation (°) |
360 |
|
Angle of Vertical Rotation (°) |
-60 ~ +70 |
|
Connecting Flange |
DIN / ANSI |
|
Service Environment |
-10℃ ~ +50℃ |
|
|
|
|
|
|
|
|
 |
|
Q1: What is the main function of a BARSS nozzle fire monitor?
A1: It delivers a high-volume water or foam stream to control or extinguish large-scale fires.
Q2: What materials are available?
A2: Common options include brass, stainless steel, and hard-coated aluminum alloy.
Q3: What’s the maximum range of the monitor?
A3: Depending on pressure, it can reach 50 to 60 meters or more.
Q4: Can it be used with foam systems?
A4: Yes, compatible with both water and firefighting foam.
