Durable and easy-to-use fire hose reel for rapid first-response fire protection. Ideal for buildings, warehouses, and commercial facilities.
CEQU Fire Hose Reel is designed for effective firefighting with a semi-rigid hose that delivers a continuous water flow. It features a swing arm or fixed mounting system, brass or plastic nozzle, and optional automatic or manual valves. The reel body is made of powder-coated steel for durability and corrosion resistance.
|
Parameter |
Specification |
Notes |
|
Model |
FHR-30M / FHR-36M |
Custom models available |
|
Hose Length |
30 meters / 36 meters |
20m / 25m / 30m / 36m optional |
|
Hose Diameter |
19mm / 25mm |
Standard: 3/4" or 1" |
|
Working Pressure |
1.0 MPa (10 bar) |
Max 1.2 MPa available |
|
Burst Pressure |
≥ 2.5 MPa (25 bar) |
Safety factor of 2.5 |
|
Reel Diameter |
480mm – 550mm |
Depends on hose length |
|
Material |
Powder-coated steel reel + PVC/Rubber hose + Brass/Plastic/Zinc nozzle |
Corrosion-resistant & durable |
|
Mounting Type |
Wall-mounted / Swing-arm mounted |
Fixed or swivel type available |
|
Outlet Connection |
1" BSP / NST / Customizable |
Compatible with different local standards |
|
Valve Type |
Automatic / Manual |
Optional based on request |
|
Color |
Red (Customizable) |
Default fire red; other colors available |
Commercial Buildings
Factories & Warehouses
Hotels & Hospitals
Underground Car Parks
Schools & Government Buildings
Swing or Fixed Type
Continuous Water Flow
Durable Steel Construction
Auto/Manual Valve Optional
Custom Length Available
Optional Brass/Plastic Nozzle
Packaging Info
1 set per carton
Custom logo printing available
Q: Is the nozzle material customizable?
A: Yes, we offer brass or plastic nozzles. Brass is more durable and preferred in high-temperature zones.
Q: Do you provide mounting brackets?
A: Yes, each hose reel includes standard wall-mounting brackets.
